La reixeta de retorn d'aletes fixes a 45º és l'opció tècnica ideal per a l'aspiració d'aire en sistemes de ventilació i aire condicionat. El seu tret distintiu són les lames horitzontals fixades amb una inclinació de 45 graus, un disseny que oculta l'interior del conducte sense sacrificar la capacitat d'extracció del sistema. Aquesta característica és fonamental per mantenir la integritat visual de les estances, evitant que es vegin la pols o els elements mecànics darrere de la reixeta.
És una solució ideal per a oficines, comerços i habitatges on es requereix un element de retorn durador i estètic. Fabricada en alumini resistent, garanteix un flux d'aire constant i silenciós gràcies a la seva baixa pèrdua de càrrega. La seva versatilitat permet la instal·lació tant en parets com en sostres, oferint un manteniment senzill i una llarga vida útil. Trieu aquesta reixeta per aconseguir un acabat professional que combina privadesa visual i una circulació d'aire òptima.
| A (mm) | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 700 | 800 | 900 | 1000 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| B (mm) | € | € | € | € | € | € | € | € | € | € | € | € | € | € |
| 100 | 19,50 Ref. 568100100 | 19,65 Ref. 568150100 | 19,82 Ref. 568200100 | 22,26 Ref. 568250100 | 24,68 Ref. 568300100 | 25,84 Ref. 568350100 | 27,01 Ref. 568400100 | 29,31 Ref. 568450100 | 31,68 Ref. 568500100 | 40,52 Ref. 568600100 | 44,64 Ref. 568700100 | 47,70 Ref. 568800100 | 51,40 Ref. 568900100 | 55,05 Ref. 5681000100 |
| 150 | 23,30 Ref. 568100150 | 23,44 Ref. 568150150 | 23,56 Ref. 568200150 | 26,07 Ref. 568250150 | 28,58 Ref. 568300150 | 30,57 Ref. 568350150 | 32,58 Ref. 568400150 | 34,53 Ref. 568450150 | 36,52 Ref. 568500150 | 47,76 Ref. 568600150 | 53,64 Ref. 568700150 | 57,06 Ref. 568800150 | 62,02 Ref. 568900150 | 66,78 Ref. 5681000150 |
| 200 | 23,92 Ref. 568100200 | 25,56 Ref. 568150200 | 28,56 Ref. 568200200 | 30,73 Ref. 568250200 | 32,58 Ref. 568300200 | 34,71 Ref. 568350200 | 36,92 Ref. 568400200 | 40,27 Ref. 568450200 | 43,61 Ref. 568500200 | 56,63 Ref. 568600200 | 62,50 Ref. 568700200 | 66,48 Ref. 568800200 | 72,60 Ref. 568900200 | 78,49 Ref. 5681000200 |
| 250 | 27,77 Ref. 568100250 | 30,24 Ref. 568150250 | 32,69 Ref. 568200250 | 34,24 Ref. 568250250 | 37,31 Ref. 568300250 | 39,13 Ref. 568350250 | 42,23 Ref. 568400250 | 45,64 Ref. 568450250 | 49,04 Ref. 568500250 | 65,37 Ref. 568600250 | 70,82 Ref. 568700250 | 75,48 Ref. 568800250 | 80,02 Ref. 568900250 | 86,53 Ref. 5681000250 |
| 300 | 32,69 Ref. 568100300 | 36,00 Ref. 568150300 | 39,34 Ref. 568200300 | 42,35 Ref. 568250300 | 45,39 Ref. 568300300 | 46,43 Ref. 568350300 | 47,51 Ref. 568400300 | 52,44 Ref. 568450300 | 55,99 Ref. 568500300 | 77,68 Ref. 568600300 | 83,57 Ref. 568700300 | 89,05 Ref. 568800300 | 94,45 Ref. 568900300 | 103,10 Ref. 5681000300 |
| 350 | 34,00 Ref. 568100350 | 37,87 Ref. 568150350 | 41,77 Ref. 568200350 | 44,82 Ref. 568250350 | 47,88 Ref. 568300350 | 50,63 Ref. 568350350 | 53,41 Ref. 568400350 | 57,80 Ref. 568450350 | 62,25 Ref. 568500350 | 85,92 Ref. 568600350 | 92,79 Ref. 568700350 | 96,23 Ref. 568800350 | 105,51 Ref. 568900350 | 117,09 Ref. 5681000350 |
| 400 | 39,03 Ref. 568100400 | 42,77 Ref. 568150400 | 46,43 Ref. 568200400 | 49,62 Ref. 568250400 | 54,37 Ref. 568300400 | 57,63 Ref. 568350400 | 60,66 Ref. 568400400 | 64,87 Ref. 568450400 | 70,32 Ref. 568500400 | 97,59 Ref. 568600400 | 106,38 Ref. 568700400 | 113,27 Ref. 568800400 | 122,61 Ref. 568900400 | 133,25 Ref. 5681000400 |
| 450 | 41,29 Ref. 568100450 | 46,02 Ref. 568150450 | 49,38 Ref. 568200450 | 53,32 Ref. 568250450 | 58,82 Ref. 568300450 | 61,85 Ref. 568350450 | 66,52 Ref. 568400450 | 70,12 Ref. 568450450 | 74,96 Ref. 568500450 | 105,30 Ref. 568600450 | 115,38 Ref. 568700450 | 123,53 Ref. 568800450 | 130,78 Ref. 568900450 | 145,42 Ref. 5681000450 |
| 500 | 45,39 Ref. 568100500 | 50,13 Ref. 568150500 | 54,90 Ref. 568200500 | 59,65 Ref. 568250500 | 64,38 Ref. 568300500 | 69,19 Ref. 568350500 | 74,02 Ref. 568400500 | 77,06 Ref. 568450500 | 83,86 Ref. 568500500 | 117,18 Ref. 568600500 | 126,36 Ref. 568700500 | 135,94 Ref. 568800500 | 144,59 Ref. 568900500 | 161,31 Ref. 5681000500 |
| 600 | 54,08 Ref. 568100600 | 58,48 Ref. 568150600 | 64,38 Ref. 568200600 | 69,75 Ref. 568250600 | 75,12 Ref. 568300600 | 80,47 Ref. 568350600 | 85,84 Ref. 568400600 | 92,07 Ref. 568450600 | 97,55 Ref. 568500600 | 140,53 Ref. 568600600 | 152,72 Ref. 568700600 | 163,45 Ref. 568800600 | 174,29 Ref. 568900600 | 194,06 Ref. 5681000600 |
| 700 | 66,55 Ref. 568100700 | 73,15 Ref. 568150700 | 79,74 Ref. 568200700 | 86,37 Ref. 568250700 | 92,92 Ref. 568300700 | 99,51 Ref. 568350700 | 106,08 Ref. 568400700 | 111,99 Ref. 568450700 | 117,95 Ref. 568500700 | 161,19 Ref. 568600700 | 176,20 Ref. 568700700 | 188,57 Ref. 568800700 | 201,02 Ref. 568900700 | 223,80 Ref. 5681000700 |
| 800 | 77,96 Ref. 568100800 | 85,56 Ref. 568150800 | 93,20 Ref. 568200800 | 100,80 Ref. 568250800 | 108,37 Ref. 568300800 | 115,98 Ref. 568350800 | 123,60 Ref. 568400800 | 131,22 Ref. 568450800 | 138,81 Ref. 568500800 | 184,04 Ref. 568600800 | 206,56 Ref. 568700800 | 213,59 Ref. 568800800 | 226,43 Ref. 568900800 | 248,58 Ref. 5681000800 |
| 900 | 80,02 Ref. 568100900 | 88,25 Ref. 568150900 | 96,48 Ref. 568200900 | 104,68 Ref. 568250900 | 112,88 Ref. 568300900 | 121,09 Ref. 568350900 | 129,34 Ref. 568400900 | 138,71 Ref. 568450900 | 148,05 Ref. 568500900 | 205,77 Ref. 568600900 | 218,61 Ref. 568700900 | 235,28 Ref. 568800900 | 254,32 Ref. 568900900 | 277,72 Ref. 5681000900 |
| 1000 | 83,51 Ref. 5681001000 | 91,88 Ref. 5681501000 | 100,24 Ref. 5682001000 | 108,59 Ref. 5682501000 | 116,99 Ref. 5683001000 | 128,95 Ref. 5683501000 | 133,76 Ref. 5684001000 | 146,14 Ref. 5684501000 | 154,73 Ref. 5685001000 | 224,51 Ref. 5686001000 | 243,28 Ref. 5687001000 | 259,28 Ref. 5688001000 | 278,92 Ref. 5689001000 | 304,15 Ref. 56810001000 |
